1-500 Nm Plug-In Torque Wrench,DA-1 Series-Torque wrenches-SAIVS

Description：

The torque wrench body is made of metal structure,sturdy and durable, with a long service life.

Accuracy: Torque error value ± 4%.

The plastic handle of the wrench is made of aluminum alloy knurled,

which has characteristics such as oil resistance, anti slip, anti drop, and durability.

The permanent torque scale on the alloy steel pipe is easy for users to read,

with a comparison between metric and English systems.

Interchangeable head design, with torque wrench head

interface sizes of 9x12 concave square head and 14x18 concave square head

Each torque wrench has a unique product identification code.

DA-1 Type Plug-in torque wrench
Model Number	Torque range		Specifications	Fine Scale/N.m		Length/mm	Width/mm	Height/mm	Weight/Kg
Model Number	N.m	Lbf.ft	Specifications	N.m	Lbf.ft	Length/mm	Width/mm	Height/mm	Weight/Kg
DA02601	1-5	2-9	9x12	0.05	0.067	208	28	28	0.4
DA02602	2-12	2-9	9x12	0.1	0.074	208	34	30	0.4
DA02603	4-20	3-15	9x12	0.2	0.147	208	34	30	0.45
DA02604	5-25	4-19	9x12	0.2	0.147	208	34	30	0.45
DA02605	6-30	5-23	9x12	0.2	0.147	268	34	30	0.48
DA02606	10-60	9-46	9x12	0.5	0.369	268	41	34	0.8
DA02607	10-100	7-75	9x12	0.5	0.369	388	41	34	0.81
DA02608	20-100	15-75	9x12	0.5	0.369	388	41	34	0.81
DA02609	25-125	20-94	9x12	0.5	0.369	388	41	34	0.81
DA02610	40-200	30-150	14x18	1.0	0.738	448	41	34	0.87
DA02611	20-210	15-155	14x18	1.0	0.738	448	41	34	0.87
DA02612	60-300	45-226	14x18	1.0	0.738	603	45	42	1.87
DA02613	65-335	50-250	14x18	1.0	0.738	603	45	42	1.87
DA02614	65-350	50-260	14x18	1.0	0.738	603	45	42	1.87
DA02615	80-400	60-300	14x18	2.0	1.475	653	45	42	1.89
DA02616	100-500	80-376	14x18	2.0	1.475	653	45	42	1.89

Application：

Infrastructure development: Used for securing road signs and traffic lights.

Steel and metal fabrication: Used for tightening steel components and metal structures.

Power plant maintenance: Used for tightening steam boilers and power generation equipment.

Shipyard maintenance: Used for tightening ship structures and equipment.

Chemical plants: Used for tightening valves, pumps, and pressure vessels.

Foundries: Used for tightening castings and molds.
